Description
The IMOU HR12F-B is a dual-band Wi-Fi router designed for stable and reliable wireless networking, ideal for homes, small offices, shops, or smart home /surveillance systems. It provides decent coverage and bandwidth for multiple devices, including cameras, smart devices, computers, and more.
Key Features
-
Dual-Band Wi-Fi (AC1200) — Delivers up to 300 Mbps on 2.4 GHz + 867 Mbps on 5 GHz, ensuring a balance between compatibility and high-speed performance.
-
Four External 5 dBi Antennas — Improve signal strength and coverage across rooms or small buildings.
-
Guest Wi-Fi + Network Security — Supports encrypted Wi-Fi (WPA-PSK / WPA2-PSK), hidden SSID, and guest-network option, suitable for secure home or business use.
-
Supports Auto-Sync with IMOU Devices — Works smoothly with IMOU cameras and smart devices through automatic configuration support.
-
Simple Setup & Management — Equipped with WPS and Reset buttons, easy to configure for users of all technical levels.
Technical Specifications
| Feature |
Details |
| Model |
HR12F-B |
| Wi-Fi Standard |
IEEE 802.11b/g/n (2.4 GHz), IEEE 802.11a/n/ac (5 GHz) |
| Speed (Theoretical) |
AC1200 (300 + 867 Mbps) |
| Antennas |
4 × 5 dBi external antennas |
| Network Ports |
1 × 100 Mbps WAN, 3 × 100 Mbps LAN ports |
| Security |
WPA-PSK / WPA2-PSK, hidden SSID support |
| Extra Features |
Guest Wi-Fi, Wi-Fi scheduling, auto-sync with IMOU devices, IPv6 support |
| Power Supply |
DC 12 V / 0.6 A |
| Operating Temp. |
–10 °C to +45 °C |
| Housing / Size |
188 × 120 × 26 mm, ~200 g |
Why Choose the HR12F-B
-
Solid dual-band performance capable of handling multiple devices simultaneously — suitable for IP cameras, smart-home gear, PCs, and TVs.
-
Four external antennas enhance signal stability and coverage, making them particularly useful for apartments, small houses, or offices.
-
Security and guest-network features provide flexibility and privacy for diverse use cases.
-
Compatibility with IMOU’s ecosystem simplifies setup for surveillance and smart-home installations.
-
Straightforward installation and management — good for non-technical users.
