Description
The PS70FP Series features dual-lens technology for simultaneous wide and focused coverage, making a single camera equivalent to two traditional cameras. Available in 6MP and 10MP, the camera delivers clear high-resolution video, smart AI detection, and active deterrence with spotlights and red-blue warning lights . Motorized pan & tilt ensures complete coverage, while IP67-rated housing provides reliable performance in any weather . Perfect for homes, stores, warehouses, and outdoor areas requiring intelligent and proactive security.
Key Features
• Dual-Lens, High-Resolution Video
-
10MP model: Two 5MP lenses (fixed + pan/tilt) provide wide coverage and detailed video.
-
6MP model: Offers a single high-resolution sensor with excellent clarity.
-
Capture every important detail with 8× digital zoom.
• Pan & Tilt Flexibility
-
Fixed Lens: Manual adjustment 0–260° pan, 0–25° tilt.
-
PT Lens: Motorized pan 0–355°, tilt 0–90° for effortless remote control.
• H.265 Smart Compression
Efficiently reduces storage requirements while maintaining sharp image quality.
• Smart Color Night Vision
Four adaptive night vision modes provide bright, full-color images even in low light.
• AIgo Play – Advanced Smart Detection
-
Human Detection
-
Vehicle Detection
-
Intrusion Detection (Human/Vehicle)
-
Crossing Line Detection (Human/Vehicle)
-
Loitering & Occlusion Detection
-
People Counting & more
• Active Deterrence
-
Built-in spotlight , 110dB siren , and red-blue warning lights
-
Instant response to intruders with combined audio-visual alerts
• Automatic Smart Tracking
Automatically follows moving objects, ensuring critical activity stays in view.
• Patrol Preset Areas
Scan preset zones automatically for complete coverage.
• All-Day Storage (AOR Mode)
Continuously records while saving storage: full-frame during events, low frame rate when idle.
• Two-Way Audio
Built-in mic & speaker allow real-time communication with visitors or family.
• Weatherproof Design
IP67-rated housing ensures reliable performance in rain, dust, and harsh outdoor conditions .
• Flexible Storage Options
Supports Cloud Storage, MicroSD (up to 512GB), and NVR solutions.
• PoE / 12V DC Power
Simplifies installation with reliable power options.
• Voice Assistant Compatibility
Works with Google Assistant & Amazon Alexa for convenient voice control .
Technical Specification
| Category |
PS70F 10MP (IPC-PS70FP-10M0) |
PS70F 6MP (IPC-PS70FP-6M0) |
| Lens |
Dual: 5MP Fixed + 5MP PT |
Single 6MP PT Lens |
| Max Resolution |
10MP total (2 × 5MP) |
6MP |
| Fixed Lens Pan/Tilt |
0–260° Pan / 0–25° Tilt |
– |
| PT Lens Pan/Tilt |
0–355° Pan / 0–90° Tilt |
0–355° Pan / 0–90° Tilt |
| Night Vision Distance |
30m (98ft) |
30m (98ft) |
| Field of View |
76° (H), 41° (V), 91° (D) |
76° (H), 41° (V), 91° (D) |
| Digital Zoom |
8× |
8× |
| Illuminators |
4 per lens (IR + Spotlight) |
4 integrated |
| Warning Lights |
Red-Blue Lights |
Red-Blue Lights |
| Video Compression |
H.265 / H.264 |
H.265 / H.264 |
| Frame Rate |
15 fps |
15 fps |
| Ethernet Port |
1 × 100Mbps |
1 × 100Mbps |
| Mobile App |
IMOU App (iOS / Android) |
IMOU App (iOS / Android) |
| Power Supply |
PoE / DC 12V 1A |
PoE / DC 12V 1A |
| Power Consumption |
<12W |
<12W |
| Material |
Plastic |
Plastic |
| Storage |
MicroSD up to 512GB |
MicroSD up to 512GB |
| Operating Temp |
–30°C to +50°C |
–30°C to +50°C |
| Operating Humidity |
<95% RH |
<95% RH |
| Dimensions (L×W×H) |
202 × 115 × 159 mm |
202 × 115 × 159 mm |
| Weight |
622g |
622g |
| Certification |
CE |
CE |
| Smart Detection |
Motion / Human / Vehicle / Intrusion / Crossing Line / Loitering / Occlusion / People Counting |
Motion / Human / Vehicle / Intrusion / Crossing Line / Loitering / Occlusion / People Counting |
| Reset Button |
Yes |
Yes |
Why You Need PS70FP Series?
-
Dual-lens technology for wide coverage + detailed PT tracking.
-
High-resolution video up to 10MP captures critical details clearly.
-
Active deterrence with spotlight , siren , and red-blue lights .
-
AI-powered detection reduces false alarms with advanced human & vehicle recognition.
-
Complete coverage via motorized pan & tilt plus patrol presets.
-
All-weather durability with IP67-rated housing .
-
Flexible storage with Cloud, MicroSD (up to 512GB), and NVR options.
-
Real-time monitoring & two-way talk through the mobile app .
-
Ideal for homes, warehouses, stores, and outdoor environments needing top-tier smart security.
