Description
The IPC‑PS3DP Series delivers versatile, high-quality surveillance for homes and businesses.
-
PS3D 5MP: 3K ultra-clear resolution, smart color night vision , AI human & vehicle detection, and built-in spotlight for deterrence.
-
PS7F 3MP: 3MP coverage with 0–355° pan & 0–90° tilt, active deterrence including spotlight , 110dB siren , and red-blue warning lights .
Both cameras feature PoE/12V DC power, multiple storage options, and durable weatherproof construction , offering reliable 24/7 monitoring.
Key Features
• High-Resolution Video
-
PS3D: 3K clarity captures fine details for faces, plates, and objects.
-
PS7F: 3MP resolution with pan & tilt ensures full coverage.
• H.265 Smart Compression
Efficient compression saves storage while keeping video quality sharp.
• Flexible Viewing Angles
• Smart Night Vision
Four adaptive modes provide clear visibility at night : Infrared, Color, Smart, and Off Mode.
• AI Detection
Detects humans and vehicles accurately, reducing false alerts.
• Active Deterrence
-
PS3D: Built-in spotlight for night deterrence.
-
PS7F: Spotlight , 110dB siren , and red-blue warning lights actively scare intruders.
• PoE / 12V DC Power
Supports flexible installation and clean cabling.
• Weatherproof Design
Durable for outdoor conditions, resistant to rain, dust, and harsh weather .
• Multiple Storage Options
Supports NVR, Cloud, or MicroSD up to 512GB with AOR Mode for optimized recording.
• Remote App Access
Control cameras, receive alerts, and view live feed via IMOU App .
Technical Specification
| Category |
PS3D 5MP |
PS7F 3MP |
| Image Sensor |
1/3” Progressive CMOS |
1/3” 3MP Progressive CMOS |
| Max Resolution |
5MP (2880 × 1620) |
3MP (2304 × 1296) |
| Frame Rate |
Up to 25/30fps |
25/30fps |
| Video Compression |
H.265 / H.264 |
H.265 / H.264 |
| Night Vision Distance |
30m (98ft) |
30m (98ft) |
| Lens / Viewing |
2.8mm / 3.6mm |
3.6mm Fixed + 0–355° Pan / 0–90° Tilt |
| Digital Zoom |
8× |
8× |
| Built-in Spotlight |
Yes |
Yes |
| Active Deterrence |
Spotlight |
Spotlight + 110dB Siren + Red-Blue Lights |
| Ethernet Port |
1 × 100Mbps |
1 × 100Mbps |
| Mobile App |
IMOU App (iOS / Android) |
IMOU App (iOS / Android) |
| Power Supply |
PoE / DC 12V 1A |
PoE / DC 12V 1A |
| Power Consumption |
<6W |
<12W |
| Material |
Plastic |
Plastic |
| Storage |
MicroSD up to 512GB |
MicroSD up to 512GB |
| Operating Temp |
–30°C to +60°C |
–30°C to +50°C |
| Operating Humidity |
<95% RH |
<95% RH |
| Dimensions |
147.7 × 74.2 × 74.2 mm |
196 × 115 × 159 mm |
| Weight |
220g |
505g |
| Certifications |
CE, Onvif |
CE, Onvif |
| Smart Detection |
Motion / Human / Vehicle |
Motion / Human / Vehicle |
Why You Need IPC‑PS3DP Series?
-
Full coverage: PS7F pan & tilt plus PS3D wide-angle lenses leave no blind spots.
-
Smart alerts: AI detects humans and vehicles for fewer false alarms.
-
Active deterrence: Spotlights , siren , and red-blue lights prevent intrusions immediately.
-
All-weather durability: Reliable performance in rain, dust, and harsh conditions .
-
Flexible installation: PoE or 12V DC support simplifies setup.
-
Secure storage: NVR, Cloud, and MicroSD up to 512GB with AOR Mode.
-
Remote monitoring: View live feed and receive alerts via mobile app .
-
Ideal for homeowners and businesses seeking smart, proactive, and reliable security.
