Description
Monitor your water tank level in real time with the Smarwish SmarLevel Ultra, an advanced wireless ultrasonic water level monitoring system designed for homes, farms, villas, commercial buildings, and industrial tanks. The system combines an IP65 ultrasonic sensor, RF433MHz long-range communication, and a 2.4GHz WiFi gateway to provide accurate tank level readings directly on your smartphone through the Smarwish App or Smart Life App.
With an ultrasonic measurement range from 0.1 to 4 meters and an accuracy of ±0.02m, SmarLevel Ultra delivers precise liquid level monitoring without direct contact with water. It also supports customizable high and low-level alarms, temperature monitoring, device sharing, and remote access from anywhere.
Whether you're monitoring rooftop water tanks, underground reservoirs, or agricultural water storage, SmarLevel Ultra provides reliable wireless performance with RF communication capable of reaching up to 1000 meters in open areas and penetrating up to 20 floors between the sensor and gateway.
Key Features
- Real-time water tank level monitoring via smartphone.
- Ultrasonic non-contact measurement technology.
- WiFi Gateway (2.4GHz) with RF433MHz communication.
- Up to 1000m RF range in open areas.
- RF signal penetration through up to 20 floors.
- Ultrasonic measuring range: 0.1m – 4m.
- High accuracy of ±0.02m.
- Adjustable High-Level and Low-Level alarms.
- Tank level percentage display (0–100%).
- Liquid depth display in meters.
- Built-in temperature monitoring.
- IP65 waterproof ultrasonic sensor.
- Supports multiple users through device sharing.
- Compatible with Smarwish App and Smart Life App.
- Easy installation with Type-C powered gateway.
- Works with AC110–240V power adapter.
Technical Specifications
| Specification |
Details |
| Brand |
Smarwish |
| Model |
SmarLevel Ultra |
| Sensor Type |
Ultrasonic Wireless Level Sensor |
| Communication |
RF433MHz |
| Gateway Connectivity |
2.4GHz WiFi + RF433MHz |
| WiFi Frequency |
2.4GHz Only |
| Sensor Measuring Range |
0.1m – 4m |
| Measurement Accuracy |
±0.02m |
| RF Range |
Up to 1000m (Open Area) |
| Wall Penetration |
Up to 20 Floors |
| Gateway to Router Distance |
Up to 50m (No Obstacles) |
| Sensor Protection |
IP65 |
| Operating Temperature |
-20°C to +70°C |
| Gateway Power |
DC 5V / 1A |
| Gateway Interface |
USB Type-C |
| Sensor Power Input |
≤100mA @ 5V DC |
| Sensor Power Supply |
AC110–240V Adapter |
| Mobile Apps |
Smarwish App / Smart Life |
| Alarm Functions |
High & Low Level Alarm |
| Device Sharing |
Yes |
Why Choose SmarLevel Ultra?
SmarLevel Ultra offers an intelligent and reliable solution for monitoring water tank levels without manual inspection. Its long-range RF communication, accurate ultrasonic sensing, smartphone connectivity, customizable alarms, and rugged IP65 design make it ideal for residential, agricultural, and commercial applications. Installation is simple, operation is maintenance-friendly, and users can monitor their tanks from anywhere using the Smart Life ecosystem.
