Description
The UGREEN HDMI to VGA + 3.5mm Audio Converter | MM103 | 40248 is an active adapter designed to connect an HDMI source device, such as a laptop, PC, or other HDMI-enabled device, to a VGA monitor, projector, or display. It converts digital HDMI video to analog VGA output and provides a separate 3.5mm stereo audio connection. The adapter supports up to 1920×1080 Full HD at 60Hz and includes a Micro-USB power port for optional supplemental power.
Key Features
-
HDMI to VGA Conversion: Connects an HDMI source to a VGA display.
-
Full HD 1080p: Supports resolutions up to 1920×1080 at 60Hz.
-
3.5mm Audio Output: Provides separate stereo audio output for speakers or headphones.
-
Optional Power Port: Includes a Micro-USB port for supplemental power when required.
-
Active Adapter: Converts HDMI digital video to VGA analog output.
-
One-Way Conversion: Supports HDMI source → VGA display only; it is not bi-directional.
-
Wide Compatibility: Suitable for laptops, PCs, projectors, monitors, and other HDMI source devices.
-
Compact Design: Approximately 25cm cable length for convenient installation and everyday use.
Key Features Summary
- HDMI Male input
- VGA Female output
- 3.5mm stereo audio output
- Micro-USB supplemental power port
- Up to 1920×1080 @ 60Hz
- HDMI to VGA only
- Active digital-to-analog conversion
- Approx. 25cm cable
- Ideal for monitors and projectors
Technical Specifications
| Specification |
Details |
| Brand |
UGREEN |
| Model |
MM103 |
| Product Number |
40248 |
| Input |
HDMI Male + Micro-USB Power Port |
| Video Output |
VGA Female |
| Audio Output |
3.5mm Stereo Audio |
| Maximum Resolution |
1920×1080 @ 60Hz |
| Conversion Direction |
HDMI to VGA |
| Bi-directional |
No |
| Cable Length |
Approx. 25cm |
| Adapter Type |
Active HDMI to VGA Converter |
| Power |
Micro-USB optional supplemental power |
