The Spark I-300 is an IP video outdoor station with a 4.5″ capacitive touch screen, a 150° wide-angle camera and IC/ID card and password access. It supports villa, building and high-rise modes, runs on PoE or DC 12 to 15 V, and can be flush or surface mounted.
Key Features
4.5″ touch screen: TFT LCD, capacitive touch, 480 × 272
Wide view: 150° horizontal viewing angle, white-LED night vision, PIR motion detection
Access: IC 13.56 MHz Mifare and ID 125 kHz EM cards (2,000), six-digit public password, Wiegand reader unlock
Lock relay: NC / NO / COM for electric or magnetic locks
System modes: villa, building and high-rise (high-rise resident list up to 999 users)
Power and cabling: PoE or DC 12 to 15 V 2 A over Cat5/Cat5e up to 100 m
Storage: SD card up to 256 GB for JPG photos
Mounting: flush or surface mount, install height 120 to 160 cm
Technical Specifications
Model
Spark I-300
Brand
Spark
Type
IP video outdoor station (door station)
Screen
4.5″ TFT LCD, capacitive touch
Resolution
480 × 272
Viewing angle
150° horizontal
Night vision
White LED
Motion detection
PIR
Video codec
H.264
SD card
Up to 256 GB, JPG photos
Intercom mode
Full duplex
Operating system
Linux
Standby display
Black screen, clock, photo frame
Ringtones
10, ring time 0 to 150 s
RFID
IC 13.56 MHz Mifare · ID 125 kHz EM
Card capacity
2,000
Wiegand
Wiegand reader unlock (D0/D1)
Relay output
NC / NO / COM
Power
PoE or DC 12 to 15 V 2 A
Working current
DC 12 V 250 mA
Standby power
< 1 W
Working temperature
-20 °C to +55 °C
Installation
Flush mount, surface mount
Cable
Cat5 / Cat5e, up to 100 m
What's in the Box
Outdoor station
Embedded box
Rubber stoppers ×4
Screws KA4×32 ×4
Screws KM3, stainless 304 ×2
Screw wrench
IC cards ×2
4-pin cable
3-pin cables ×2
2-pin cables ×2
User manual
Downloads
⬇ Download Datasheet (PDF)
Buy the Spark I-300 IP video door station in Jordan from Bestways Smart-home Solutions.
The Spark I-220 is an IP video outdoor unit with fingerprint and IC card unlocking, a 110° camera with white-LED night light and full-duplex intercom. It is rated IP65 and powered by PoE or DC 12 V over a Cat5 network cable.
Key Features
Fingerprint unlock: 500 fingerprints, registered from the indoor unit and kept separate per household
IC cards: 1,000 cards, 13.56 MHz
Camera: 110° viewing angle with white LED compensation light
Intercom: full duplex, 45 s messages, 120 s call duration
System size: up to 4 door units (DIP switch) and up to 6 IP cameras
Power: DC 12 V or PoE, max. 200 mA (adapter optional)
Weatherproof: IP65, -40 °C to +50 °C
Unlock options: indoor unit, fingerprint, card and exit button
Technical Specifications
Model
Spark I-220
Brand
Spark
Type
IP video outdoor station (door station)
Viewing angle
110°
Night light
White LED compensation
Intercom
Full duplex
Ringtone time
30 / 60 / 90 s
Ringtone volume
1 to 15
Message time
45 s
Call duration
120 s
Door units per system
Up to 4 (DIP switch)
IP cameras
Up to 6
Fingerprints
500
IC cards
1,000 · 13.56 MHz
Unlock
Indoor unit, fingerprint, card, exit button
Connection
Cat5 network cable
Power supply
DC 12 V or PoE
Power consumption
Max. 200 mA
Power adapter
Optional
Waterproof rating
IP65
Working temperature
-40 °C to +50 °C
Installation
Surface / flush mount, install height 120 to 160 cm
What's in the Box
Outdoor station
Plastic anchors ×4
Screws ×8
7-pin line
4-pin line
2-pin line
IC cards ×2
User manual
Downloads
⬇ Download Datasheet (PDF)
Buy the Spark I-220 IP video door station in Jordan from Bestways Smart-home Solutions.
The Spark I-100 is a slim, single-button IP video door station for homes, villas and small buildings. It has a 2.0 MP camera with infrared night vision, full-duplex intercom and NFC card unlocking, and is powered by PoE or DC 12 to 15 V. Settings are made from the indoor monitor.
Key Features
2.0 MP camera: with infrared compensation LEDs for night viewing
Full-duplex intercom: both sides talk at the same time
NFC card unlock: or unlock from the indoor monitor
Detection: motion detection and human detection
Two locks: Lock 1 (NO / NC) and Lock 2, each with exit-button and door-contact input
Power: PoE or DC 12 to 15 V / 1 A; standby < 1.5 W
Cabling: Cat5 / Cat5e < 50 m to the monitor, lock RVV 2×1.0 < 10 m
Technical Specifications
Model
Spark I-100
Brand
Spark
Type
IP outdoor station
Camera
2.0 MP
Night vision
Infrared compensation LEDs
Intercom
Full duplex
Unlocking
NFC card, from the indoor monitor
Card reader
NFC
Operating system
Linux
Network
RJ45, DHCP
Power
PoE or DC 12 to 15 V / 1 A
Working current
Max 300 mA at DC 15 V
Standby power
< 1.5 W
Working temperature
-10 °C to +55 °C
Motion detection
Yes
Human detection
Yes
Lock outputs
Lock 1 (NO / NC), Lock 2
Inputs
Exit button + door contact per lock
Installation
Surface mount
Cabling
Cat5 / Cat5e < 50 m · lock RVV 2×1.0 < 10 m
What's in the Box
Door station
Wall mount
NFC cards ×2
7-pin, 5-pin and 2-pin cables
Anchors and screws ×4
Box screws ×2
User manual
Downloads
⬇ Download Datasheet (PDF)
Buy the Spark I-100 IP video door station in Jordan from Bestways Smart-home Solutions.
The Spark I-50 is a slim, single-button IP video door station for homes and villas. Visitors are shown on the indoor monitor through a 2.0 MP, 120° camera with infrared night vision, and residents unlock with an IC card tap. It is powered by PoE or DC 12 to 15 V.
Key Features
2.0 MP camera: 120° viewing angle, infrared compensation LEDs
Full-duplex intercom: both sides talk at the same time
IC card unlock: or unlock from the indoor monitor
Detection: motion detection and human detection
Two locks: Lock 1 (NO / NC) and Lock 2, each with exit-button and door-contact input
Power: PoE or DC 12 to 15 V / 1 A; standby < 1.5 W
Cabling: Cat5 / Cat5e < 50 m to the monitor, lock RVV 2×1.0 < 10 m
Technical Specifications
Model
Spark I-50
Brand
Spark
Type
IP outdoor station
Camera
2.0 MP
Viewing angle
120°
Night vision
Infrared compensation LEDs
Intercom
Full duplex
Unlocking
IC card, from the indoor monitor
Operating system
Linux
Network
RJ45, DHCP
Power
PoE or DC 12 to 15 V / 1 A
Working current
Max 300 mA at DC 15 V
Standby power
< 1.5 W
Working temperature
-10 °C to +55 °C
Motion detection
Yes
Human detection
Yes
Lock outputs
Lock 1 (NO / NC), Lock 2
Inputs
Exit button + door contact per lock
Installation
Surface mount
Cabling
Cat5 / Cat5e < 50 m · lock RVV 2×1.0 < 10 m
What's in the Box
Door station
Wall mount
IC cards ×2
7-pin, 5-pin and 2-pin cables
Anchors and screws ×4
Box screws ×2
User manual
Downloads
⬇ Download Datasheet (PDF)
Buy the Spark I-50 IP video door station in Jordan from Bestways Smart-home Solutions.
The Spark S-210 is a 10-inch IPS integrated IP video intercom indoor monitor. See who is at the door, talk in full duplex and unlock with one tap, monitor outdoor stations and manage alarm zones from the wall panel. It is PoE powered over one Cat5/Cat5e cable and works with the Tuya smart-home app.
Key Features
10″ IPS display: for calls, cameras and alarms
Answer the door: visitor video with the outdoor unit's room number, full-duplex audio and one-tap relay unlock
Record: JPG snapshots and video clips to SD card (< 32 GB)
Monitoring: view any outdoor station, switch channels and talk two-way
Security zones: smoke, gas, door-magnet, infrared, window-magnet, glass-break and emergency detectors; NO/NC per zone, 60 s arming countdown, 6-digit disarm password
Tuya smart home: control calls, alarm zones, settings and recordings from the app
One cable: PoE over Cat5/Cat5e (DC 15 V, max 350 mA), standby < 2.5 W
Indoor lock: can also open a lock wired to the monitor's own relay
Technical Specifications
Model
Spark S-210
Brand
Spark
Type
IP video intercom indoor monitor
Screen
10″ IPS LCD
Video input
Digital
Video codec
H.264
Picture format
JPG
Max SD card
< 32 GB
Intercom mode
Digital duplex
Microphone
Built-in
Power supply
PoE / DC 15 V 1 A
Working current
Max 350 mA
Standby
< 2.5 W
Network
DHCP, PoE
Platform
Tuya
Operating system
Linux
Motion detection
Yes
Person detection
Yes (via outdoor station)
Working temperature
-10 °C to +50 °C
Installation
Wall / surface mount
Cabling
UTP Cat5/Cat5e to door station, max 50 m · lock RVV 2×1.0, up to 10 m
System size
Up to 100 indoor monitors per outdoor station
What's in the Box
Indoor monitor
Wall bracket
2-pin cable ×2
7-pin cable
10-pin cable
Screws and anchors ×4
User manual
Downloads
⬇ Download Datasheet (PDF)
Buy the Spark S-210 IP video intercom indoor monitor in Jordan from Bestways Smart-home Solutions.
The Spark S-208 is an 8-inch IPS integrated IP video intercom indoor monitor. See who is at the door, talk in full duplex and unlock with one tap, monitor outdoor stations and manage alarm zones from the wall panel. It is PoE powered over one Cat5/Cat5e cable and works with the Tuya smart-home app.
Key Features
8″ IPS display: for calls, cameras and alarms
Answer the door: visitor video with the outdoor unit's room number, full-duplex audio and one-tap relay unlock
Record: JPG snapshots and video clips to SD card (< 32 GB)
Monitoring: view any outdoor station, switch channels and talk two-way
Security zones: smoke, gas, door-magnet, infrared, window-magnet, glass-break and emergency detectors; NO/NC per zone, 60 s arming countdown, 6-digit disarm password
Tuya smart home: control calls, alarm zones, settings and recordings from the app
One cable: PoE over Cat5/Cat5e (DC 15 V, max 350 mA), standby < 2.5 W
Indoor lock: can also open a lock wired to the monitor's own relay
Technical Specifications
Model
Spark S-208
Brand
Spark
Type
IP video intercom indoor monitor
Screen
8″ IPS LCD
Video input
Digital
Video codec
H.264
Picture format
JPG
Max SD card
< 32 GB
Intercom mode
Digital duplex
Microphone
Built-in
Power supply
PoE / DC 15 V 1 A
Working current
Max 350 mA
Standby
< 2.5 W
Network
DHCP, PoE
Platform
Tuya
Operating system
Linux
Motion detection
Yes
Person detection
Yes (via outdoor station)
Working temperature
-10 °C to +50 °C
Installation
Wall / surface mount
Cabling
UTP Cat5/Cat5e to door station, max 50 m · lock RVV 2×1.0, up to 10 m
System size
Up to 100 indoor monitors per outdoor station
What's in the Box
Indoor monitor
Wall bracket
2-pin cable ×2
7-pin cable
10-pin cable
Screws and anchors ×4
User manual
Downloads
⬇ Download Datasheet (PDF)
Buy the Spark S-208 IP video intercom indoor monitor in Jordan from Bestways Smart-home Solutions.
The Spark S-107 is a 7-inch IPS IP video intercom indoor monitor. See who is at the door, talk in full duplex and unlock with one tap, monitor outdoor stations and manage alarm zones from the wall panel. It is PoE powered over one Cat5/Cat5e cable and works with the Tuya smart-home app.
Key Features
7″ IPS display: for calls, cameras and alarms
Answer the door: visitor video with the outdoor unit's room number, full-duplex audio and one-tap relay unlock
Record: JPG snapshots and video clips to SD card (< 32 GB)
Monitoring: view any outdoor station, switch channels and talk two-way
Security zones: smoke, gas, door-magnet, infrared, window-magnet, glass-break and emergency detectors; NO/NC per zone, 60 s arming countdown, 6-digit disarm password
Tuya smart home: control calls, alarm zones, settings and recordings from the app
One cable: PoE over Cat5/Cat5e (DC 15 V, max 350 mA), standby < 2.5 W
Indoor lock: can also open a lock wired to the monitor's own relay
Technical Specifications
Model
Spark S-107
Brand
Spark
Type
IP video intercom indoor monitor
Screen
7″ IPS LCD
Video input
Digital
Video codec
H.264
Picture format
JPG
Max SD card
< 32 GB
Intercom mode
Digital duplex
Microphone
Built-in
Power supply
PoE / DC 15 V 1 A
Working current
Max 350 mA
Standby
< 2.5 W
Network
DHCP, PoE
Platform
Tuya
Operating system
Linux
Motion detection
Yes
Person detection
Yes (via outdoor station)
Working temperature
-10 °C to +50 °C
Installation
Wall / surface mount
Cabling
UTP Cat5/Cat5e to door station, max 50 m · lock RVV 2×1.0, up to 10 m
System size
Up to 100 indoor monitors per outdoor station
What's in the Box
Indoor monitor
Wall bracket
2-pin cable ×2
7-pin cable
10-pin cable
Screws and anchors ×4
User manual
Downloads
⬇ Download Datasheet (PDF)
Buy the Spark S-107 IP video intercom indoor monitor in Jordan from Bestways Smart-home Solutions.
The Spark S-110 is a 10-inch IP video intercom indoor monitor with a touch screen. See and talk to visitors and let them in from the wall or from your phone over Wi-Fi. It also monitors cameras and runs 8 wired alarm zones, and is powered by PoE or DC 15 V.
Key Features
10″ IPS touch screen: Linux, English, Arabic, Russian and Chinese interface
Full-duplex intercom: digital, with H.264 video decoding
App control: yes, via Wi-Fi
4 views: door 1, door 2, camera 1, camera 2
Alarm: 8 defence zones (S1 to S8), NO / NC; arming countdown 30 to 120 s (60 s default); six-digit disarm password
Interfaces: lock relay (NO / NC), exit, doorbell, chime, RS-485
Network: RJ45 (PoE) and Wi-Fi, DHCP or static IP
Storage: SD card up to 32 GB, JPG pictures
Technical Specifications
Model
Spark S-110
Brand
Spark
Type
IP video intercom indoor monitor
Screen
10″ IPS LCD, touch
Operating system
Linux
Video input
Digital, H.264 decoding
Intercom
Digital full duplex
App control
Yes, via Wi-Fi
Languages
English, Arabic, Russian, Chinese
Power
PoE switch or DC 15 V 1 A
Working current
DC 15 V, max 350 mA
Standby power
< 2.5 W
Working temperature
-10 °C to +50 °C
Motion detection
Yes
Person detection
Depends on outdoor station
Storage
SD card up to 32 GB, JPG pictures
Network
RJ45 (PoE), Wi-Fi · DHCP / static IP
Alarm inputs
8 defence zones (S1 to S8), NO / NC
Other interfaces
Lock relay (NO / NC), exit, doorbell, chime, RS-485
Installation
Wall / surface mount, 150 to 160 cm
Cabling
Cat5/Cat5e < 50 m to door station · lock RVV 2×1.0 < 10 m
System size
< 100 indoor extensions; rooms 0001 to 9999; extensions up to 99
What's in the Box
Indoor monitor
Wall bracket
2-pin cable ×2
7-pin cable
10-pin cable
Screws and anchors ×4
User manual
Downloads
⬇ Download Datasheet (PDF)
Buy the Spark S-110 IP video intercom indoor monitor in Jordan from Bestways Smart-home Solutions.
The Spark S-303 is a Face ID Ethernet IP video intercom kit: a 7″ IPS touchscreen indoor monitor paired with a 3.0 MP binocular outdoor station. Residents unlock with Face ID (with liveness detection) or an IC card, and the kit is controlled from the Tuya / Smart Life app. Power is PoE or DC 24 V.
Key Features
Face ID: binocular lens with liveness detection
3.0 MP camera: FHD 1080P H.264 video, 140° viewing angle, automatic infrared night vision
IC card access: built-in card reader on the outdoor station
7″ IPS touch monitor: 1024 × 600, side buttons for answer and unlock, 8 Ω 2 W speaker
Recording: snapshots and video to SD card up to 128 GB
Tuya / Smart Life: remote door calls and live view from the app
Outdoor build: aluminium alloy, IP65, -30 °C to +50 °C, 140 × 60 × 25 mm
Power: PoE or DC 24 V; outdoor unit powered via the indoor unit or PoE
Technical Specifications
Model
Spark S-303
Brand
Spark
Kit
Indoor monitor + outdoor station (model numbers not stated)
Indoor – Screen
7″ IPS, touchscreen
Indoor – Resolution
1024 × 600
Indoor – Video input
FHD 1080P
Indoor – Video codec
H.264
Indoor – Speaker
8 Ω, 2 W
Indoor – Intercom mode
Full duplex
Indoor – SD card
Up to 128 GB
Indoor – Platform
Tuya / Smart Life
Indoor – Power
DC 24 V / PoE
Indoor – Standby power
≤ 2 W
Indoor – Working temperature
-30 °C to +50 °C
Indoor – Installation
Surface mount
Outdoor – Camera
3.0 MP binocular HD
Outdoor – Video
FHD 1080P, H.264
Outdoor – Viewing angle
140°
Outdoor – Face unlock
Binocular lens, liveness detection
Outdoor – Night vision
Infrared
Outdoor – Access control
Face ID · IC card
Outdoor – Body
Aluminium alloy
Outdoor – Dimensions
140 × 60 × 25 mm
Outdoor – Protection
IP65
Outdoor – Power
DC 24 V / 200 mA
Outdoor – Standby power
≤ 2.4 W
Outdoor – Working temperature
-30 °C to +50 °C
Outdoor – Installation
Surface mount
Cabling
Indoor–outdoor UTP Cat5/Cat5e, up to 50 m · lock RVV 2×1.0, up to 10 m
Lock relay
One motor-operated lock, 12 V, max 500 mA instantaneous
What's in the Box
Indoor monitor
Outdoor station
Wall brackets
Cat5 terminals
IC cards ×2
Screws and anchors
User manual
Downloads
⬇ Download Datasheet (PDF)
Buy the Spark S-303 IP video intercom kit in Jordan from Bestways Smart-home Solutions.
The Spark S-302 is an Ethernet IP video intercom kit: a 7″ IPS touchscreen indoor monitor and a 3.0 MP outdoor station with a 140° view. Visitors are answered in full duplex, residents unlock with an IC card, and the system is controlled from the Tuya / Smart Life app. Power is PoE or DC 24 V.
Key Features
3.0 MP camera: FHD 1080P H.264 video, 140° viewing angle, infrared night vision
IC card access: card reader on the outdoor station
7″ IPS touch monitor: 1024 × 600, 8 Ω 2 W speaker, full-duplex audio
Recording: snapshots and video to SD card up to 128 GB
Tuya / Smart Life: app control of the intercom
Outdoor build: aluminium alloy, IP65, -30 °C to +50 °C, 140 × 60 × 25 mm
Power: PoE or DC 24 V; outdoor unit powered via the indoor unit or PoE
Technical Specifications
Model
Spark S-302
Brand
Spark
Kit
Indoor monitor + outdoor station (model numbers not stated)
Indoor – Screen
7″ IPS, touchscreen
Indoor – Resolution
1024 × 600
Indoor – Video input
FHD 1080P
Indoor – Video codec
H.264
Indoor – Speaker
8 Ω, 2 W
Indoor – Intercom mode
Full duplex
Indoor – SD card
Up to 128 GB
Indoor – Platform
Tuya / Smart Life
Indoor – Power
DC 24 V / PoE
Indoor – Standby power
≤ 2 W
Indoor – Working temperature
-30 °C to +50 °C
Indoor – Installation
Surface mount
Outdoor – Camera
3.0 MP HD
Outdoor – Video
FHD 1080P, H.264
Outdoor – Viewing angle
140°
Outdoor – Night vision
Infrared
Outdoor – Access control
IC card
Outdoor – Body
Aluminium alloy
Outdoor – Dimensions
140 × 60 × 25 mm
Outdoor – Protection
IP65
Outdoor – Power
DC 24 V / 200 mA
Outdoor – Standby power
≤ 2.4 W
Outdoor – Working temperature
-30 °C to +50 °C
Outdoor – Installation
Surface mount
Cabling
Indoor–outdoor UTP Cat5/Cat5e, up to 50 m · lock RVV 2×1.0, up to 10 m
Lock relay
One motor-operated lock, 12 V, max 500 mA instantaneous
What's in the Box
Indoor monitor
Outdoor station
Wall brackets
Cat5 terminals
IC cards ×2
Screws and anchors
User manual
Downloads
⬇ Download Datasheet (PDF)
Buy the Spark S-302 IP video intercom kit in Jordan from Bestways Smart-home Solutions.
The Spark S-301 is sold by Spark as a 2-wire IP video intercom kit: a 7″ IPS touchscreen indoor monitor and a 3.0 MP outdoor station with a 140° view. Residents unlock with an IC card or with one tap from the call screen, and the kit is controlled from the Tuya / Smart Life app. Power is PoE or DC 24 V.
Key Features
3.0 MP camera: FHD 1080P H.264 video, 140° viewing angle, infrared night vision
IC card access: card reader on the outdoor station
7″ IPS touch monitor: 1024 × 600, side buttons for answer and unlock, 8 Ω 2 W speaker
Recording: JPG snapshots and video to SD card up to 128 GB
Tuya / Smart Life: app control of the intercom
Outdoor build: aluminium alloy, IP65, -30 °C to +50 °C, 140 × 60 × 25 mm
Power: PoE or DC 24 V; outdoor unit powered via the indoor unit or PoE
Technical Specifications
Model
Spark S-301
Brand
Spark
Kit
Indoor monitor + outdoor station (model numbers not stated)
Indoor – Screen
7″ IPS, touchscreen
Indoor – Resolution
1024 × 600
Indoor – Video input
FHD 1080P
Indoor – Video codec
H.264
Indoor – Speaker
8 Ω, 2 W
Indoor – Intercom mode
Full duplex
Indoor – SD card
Up to 128 GB
Indoor – Platform
Tuya / Smart Life
Indoor – Power
DC 24 V / PoE
Indoor – Standby power
≤ 2 W
Indoor – Working temperature
-30 °C to +50 °C
Indoor – Installation
Surface mount
Outdoor – Camera
3.0 MP HD
Outdoor – Video
FHD 1080P, H.264
Outdoor – Viewing angle
140°
Outdoor – Night vision
Infrared
Outdoor – Access control
IC card
Outdoor – Body
Aluminium alloy
Outdoor – Dimensions
140 × 60 × 25 mm
Outdoor – Protection
IP65
Outdoor – Power
DC 24 V / 200 mA
Outdoor – Standby power
≤ 2.4 W
Outdoor – Working temperature
-30 °C to +50 °C
Outdoor – Installation
Surface mount
Cabling
Indoor–outdoor UTP Cat5/Cat5e, up to 50 m · lock RVV 2×1.0, up to 10 m
Lock relay
One motor-operated lock, 12 V, max 500 mA instantaneous
What's in the Box
Indoor monitor
Outdoor station
Wall brackets
Cat5 terminals
IC cards ×2
Screws and anchors
User manual
Downloads
⬇ Download Datasheet (PDF)
Buy the Spark S-301 IP video intercom kit in Jordan from Bestways Smart-home Solutions.
The Hikvision DS-KV8413-WME1 is a 4-button metal IP villa door station. Its 2MP HD camera with a high-performance CMOS sensor, 129° horizontal / 75° vertical field of view, 120 dB WDR and IR supplement light up to 3 m shows visitors clearly in different lighting conditions.
The four call buttons let one door station serve up to four indoor stations, for example four apartments or families in one building. A built-in Mifare card reader, 2.4 GHz Wi-Fi, standard PoE or 12 VDC power and a surface-mount housing rated IP65 and IK8 complete the package.
Note: this is an IP video intercom door station. Pair it with Hikvision IP indoor stations on the same network (see "Works With" below).
Key Features
2MP HD camera with high-performance CMOS sensor
IR supplement light up to 3 m; 120 dB WDR, BLC and DNR
129° horizontal / 75° vertical field of view
4 call buttons
Built-in Mifare card reader (13.56 MHz) for access control
2.4 GHz Wi-Fi and standard PoE (IEEE 802.3af) or 12 VDC
Noise suppression and echo cancellation
Web interface and remote configuration
Tamper alarm
Surface mount, IP65 and IK8 protection
Works With
Hikvision IP indoor stations: DS-KH6320-WTE1 (7"), DS-KH6320-LE1(B) (7"), DS-KH8350-WTE1 (7"), DS-KH8520-WTE1 (10.1"), DS-KH9510-WTE1 (10.1") and DS-KH6000-E1 (screenless)
Technical Specifications
Specification
Details
Model
DS-KV8413-WME1
Product Name
4-Button Metal Villa Door Station (Surface Mount)
Operating System
Embedded Linux
Camera
2MP HD camera
Resolution
Main stream 1920 × 1080 / 720p; sub stream 704 × 576
Stream
Main stream 1080p @ 30 fps; sub stream D1 @ 25 fps
Field of View
Horizontal 129°, vertical 75°
WDR
120 dB
BLC / DNR
Supported
Night Vision
Low illumination; IR supplement light up to 3 m
Motion Detection
Supported
Video Compression
H.264
Audio
Two-way audio; built-in omnidirectional microphone and loudspeaker; noise suppression and echo cancellation
Audio Compression
G.711u, 64 Kbps
Call Buttons
4
Card Reader
Mifare, 13.56 MHz
Network
10/100 Mbps Ethernet; 2.4 GHz Wi-Fi
Communication Protocol
TCP/IP, RTSP
Interfaces
2 relays, 1 RS-485, 4 alarm inputs, 1 tamper switch, 1 debugging port
TF Card
Supported
Indicators
3
Power Supply
Standard PoE (IEEE 802.3af); 12 VDC
Power Consumption
< 10 W
Protection
IP65, IK8
Installation
Surface mounting
Working Temperature
-40 °C to 53 °C
Working Humidity
10% to 95%
Dimensions
174 × 91 × 29 mm
Why Choose the Hikvision DS-KV8413-WME1?
Four call buttons: one door station for up to four indoor stations
Clear 2MP video with WDR and IR night vision
Card access with the built-in Mifare reader
Easy installation with Wi-Fi, standard PoE or 12 VDC
Weather and vandal resistant: IP65 and IK8
Warranty: 12-month warranty from the Official Distributor.
Looking for a smart door peephole camera in Jordan to see and talk to whoever is at your door? The IMOU VD3 starts from 99 JOD at Bestways, the official IMOU distributor in Jordan, with one unified price at every authorised dealer and a 12-month warranty from the official distributor. Make sure your door is 35–102 mm thick with a 15–35 mm peephole bore.
The IMOU VD3 (D3B-B-5X0S) is a smart door view camera with two-way audio. Its 0.98 mm fisheye lens covers 170° horizontally and vertically to capture every corner of your doorstep in 5MP (2880 × 1620), and the 4.3-inch color screen inside the door shows the outside view instantly. Dual-band 2.4 / 5 GHz Wi-Fi 6 keeps it connected for remote viewing and intercom in the IMOU app.
PIR sensing with IMOU AI human detection filters out non-human movement, while loitering detection and package detection tell you when someone lingers at the door or a parcel is delivered or picked up. Visitors can press the one-touch call button to video-call your phone, so you never miss a knock. Custom privacy masking blocks areas such as a neighbour's doorway from recording and detection. It runs on a 4800 mAh rechargeable battery and stores video on microSD up to 512GB.
Note: fits doors 35–102 mm thick with a 15–35 mm peephole bore; charge via the Type-C port (DC 5V 2A). Available options: peephole only, or with a 64GB microSD card (+15 JOD) or a 128GB microSD card (+25 JOD).
Key Features
5MP (2880 × 1620) with a 0.98 mm fisheye lens: 170° horizontal and vertical view
4.3-inch non-touch color screen (480 × 272) inside the door
PIR + AI human detection for more accurate alerts
Loitering detection and AI package detection
One-touch video call to the IMOU app and two-way talk
Custom privacy masking areas for neighbour privacy
Dual-band 2.4 / 5 GHz Wi-Fi 6
4800 mAh rechargeable battery, Type-C charging
microSD storage up to 512GB
Fits doors 35–102 mm thick and 15–35 mm peephole bores
Works With
Imou app (iOS / Android) for live view, video calls, playback and alerts
microSD storage: IMOU ST2-64-S1 64GB or IMOU ST2-128-S1 128GB microSD card
Technical Specifications
Specification
Details
Model
D3B-B-5X0S
Product Name
VD3 5MP
Image Sensor
1/3" Progressive CMOS
Resolution
5MP (2880 × 1620)
Lens
0.98 mm fisheye
Field of View
170° (H), 170° (V)
Video
Up to 15 fps; 8× digital zoom
Video Compression
H.265 / H.264
Screen
4.3-inch non-touch color screen, 480 × 272
Buttons
Call button; power button; record & capture button; reset button
Audio
Built-in mic & speaker; two-way talk
Smart Detection
PIR + AI human detection; loitering detection; package detection; low-battery notification
Privacy
Custom privacy masking areas
Wi-Fi
IEEE 802.11b/g/n/ax (Wi-Fi 6), dual-band 2.4 / 5 GHz, 120 m open field
App
Imou (iOS, Android)
Storage
microSD up to 512GB
Battery
4800 mAh rechargeable
Power Supply
DC 5V 2A (Type-C)
Door Compatibility
Door thickness 35–102 mm; peephole bore 15–35 mm
Working Temperature
-20°C ~ +50°C (-4°F ~ 122°F)
Charging Temperature
0°C ~ +45°C (32°F ~ 113°F)
Dimensions
Screen: 115 × 81 × 18 mm; lens: 65 × 65 × 52 mm
Weight
368 g (0.81 lb)
Certifications
CE, MSDS
What's in the Box
1 × Peephole
1 × Installation rack
1 × Color ring
1 × Pack of screws
1 × 3M sticker
1 × Power cable
1 × Quick start guide
Why Choose the IMOU VD3?
See who is outside on the 4.3-inch screen or on your phone
Visitors can call you with one touch – wherever you are
Package and loitering alerts focus on what matters
Replaces a standard peephole without wiring
Downloads
⬇ Download Datasheet (PDF)
Warranty: 12-month warranty from the Official Distributor.
Smart intercom systems are modern communication and access control solutions that allow users to communicate with visitors, verify their identity, and control access remotely. With features such as video calling, mobile notifications, two-way audio, and remote door unlocking, smart intercoms provide a convenient and secure way to manage entry to homes, offices, apartments, and commercial buildings.
