Looking for a Zigbee and Thread coordinator in Jordan for your Home Assistant or Zigbee2MQTT smart home? The SONOFF Dongle Max (Dongle-M) costs 50 JOD at Bestways, the exclusive SONOFF distributor in Jordan, with one unified price at every authorised dealer and a 12-month warranty from the official distributor.
The SONOFF Dongle Max (Dongle-M) is a Zigbee/Thread coordinator built on the powerful combination of EFR32MG24 + ESP32D0WDR2 for outstanding processing capability, stability and room for future expansion. It connects over Ethernet with PoE, Wi-Fi or USB, so you can place it wherever coverage is best, even far from your server or router.
A web-based console brings device status, settings, logs and alerts together in one place, and lets you switch or update firmware to run it as a Zigbee coordinator, router or Thread RCP, with no disassembly or manual flashing. Dual adjustable 5dBi antennas give 360° coverage, and the aluminum housing is tested with 24-hour salt spray and certified by CE, FCC and RoHS.
Note: the Dongle-M is designed for open platforms such as Home Assistant (ZHA) and Zigbee2MQTT.
Key Features
- EFR32MG24 + ESP32D0WDR2 chipset for performance headroom and stability
- Flexible connection: Ethernet (RJ45), Wi-Fi 2.4GHz or USB Type-C
- PoE support (48V ⎓ 0.25A): one cable for power and data
- Web-based management console with device status, settings, logs and alerts
- Switch or update firmware from the web interface: Zigbee coordinator, router or Thread RCP
- Dual adjustable 5dBi antennas for 360° signal coverage
- Aluminum housing tested with 24-hour salt spray; CE, FCC and RoHS certified
- Works with Home Assistant (ZHA) and Zigbee2MQTT
Works With
Technical Specifications
| Specification |
Details |
| Model |
Dongle-M (Dongle Max) |
| Chip |
EFR32MG24 + ESP32-D0WDR2 |
| Supported Protocols / Firmware |
Zigbee 3.0 coordinator / router; Thread RCP – switched from the web console |
| Matter / Thread Support |
Yes – Thread RCP firmware |
| Host Interface |
Ethernet RJ45 (PoE), Wi-Fi IEEE 802.11 b/g/n 2.4GHz, USB Type-C |
| Antenna |
Dual adjustable 5dBi antennas |
| Rated Input |
5V ⎓ 1A (Type-C) or 48V ⎓ 0.25A (PoE) |
| Supported Platforms |
Home Assistant, Zigbee2MQTT |
| Working Temperature |
-10°C ~ 60°C |
| Casing Material |
Aluminum, PC+ABS |
| Color |
Dim gray |
| Certifications |
CE, FCC, RoHS |
Why Choose the SONOFF Dongle-M?
- Network-connected coordinator that you can place anywhere on your LAN
- PoE for a single, tidy cable for power and data
- Simple web-based management and firmware updates
- Durable aluminum build for long-term reliability
Compare SONOFF Dongles
Not sure which dongle fits your setup? Compare all six models side by side. Zigbee and Z-Wave are different protocols: Zigbee dongles work only with Zigbee devices, and the Z-Wave dongle only with Z-Wave devices.
| Specification |
Dongle-M |
Dongle-PMG24 |
Dongle-LMG21 |
ZBDongle-P |
ZBDongle-E |
Dongle-PZG23 |
| Protocol |
Zigbee 3.0 / Thread |
Zigbee 3.0 / Thread |
Zigbee 3.0 / Thread |
Zigbee 3.0 |
Zigbee 3.0 |
Z-Wave 800 / Z-Wave Long Range |
| Chip |
EFR32MG24 + ESP32D0WDR2 |
EFR32MG24 |
EFR32MG21 |
TI CC2652P + CP2102(N) |
EFR32MG21 |
EFR32ZG23 |
| Connection |
Ethernet (PoE), Wi-Fi or USB-C |
USB |
USB |
USB |
USB |
USB |
| Antenna |
Dual adjustable 5dBi |
3dBi (optimized up to 4.5dBi) |
2dBi gain |
External SMA, +20dBm |
External, +20dBm |
2dBi external, adjustable angle |
| Signal range |
— |
Up to 200 m (line of sight) |
Up to 135 m (line of sight) |
— |
— |
— |
| Firmware roles |
Zigbee coordinator, router, Thread RCP |
Zigbee coordinator, router, OpenThread RCP, MultiPAN RCP |
Zigbee coordinator, router, OpenThread RCP, MultiPAN RCP |
Pre-flashed Z-Stack coordinator (re-flashable) |
Pre-flashed coordinator (re-flashable) |
Z-Wave controller |
| Power input |
5V 1A (USB-C) or 48V 0.25A (PoE) |
5V 500mA |
5V 500mA |
5V (100mA max) |
5V (100mA max) |
5V 500mA |
| USB extension cable |
— |
Included (1 m) |
Included (0.5 m) |
— |
— |
Included |
| Works with |
Home Assistant (ZHA), Zigbee2MQTT |
Home Assistant (ZHA), Zigbee2MQTT, openHAB |
Home Assistant (ZHA), Zigbee2MQTT, openHAB |
Home Assistant (ZHA), Zigbee2MQTT |
Home Assistant, Zigbee2MQTT, openHAB |
Home Assistant, openHAB |
| Best for |
Placing the coordinator anywhere on your network with one PoE cable |
Large Zigbee/Thread networks and the latest MG24 chip |
Compact size and a lower price for Zigbee/Thread |
Proven TI chip with strong +20dBm signal |
Ready-to-use Zigbee coordinator with Green Power support |
Z-Wave devices, including Z-Wave Long Range |
Downloads
⬇ Download Quick Start Guide (PDF)
Warranty: 12-month warranty from the Official Distributor.
